Snapper XD SXD19PWM82 User Manual

INSTALLING THE UPPER HANDLE (See Figure 3)
• Align the mounting holes on the upper handle (1) and the lower handle (2). Insert the bolts (3) and use the knobs (4) to
tighten them. Repeat the operation on the other side.
ASSEMBLY
10
Fig. 3
(4)
(4)
(2)
(1)
(3)
Not for Reproduction

Snapper XD SXD19PWM82 Specifications

General

Brand	Snapper
Model	XD SXD19PWM82
Category	Lawn Mower
Language	English
