SERVICE SCHEDULE
ITEM SERVICE PERFORMED REF. EACH
USE
5
HRS
25
HRS
50
HRS
75
HRS
100
HRS
EACH
SEASON
Engine Oil
Check Oil Level Page 10
X
Initial Oil Change Page 15
X
Periodic Oil Change Page 16
X*
Change Oil Filter Engine Manual
X
Air Cleaner
Clean or Replace Engine Manual
X
Fuel Filter
Replace Page 18
X
Engine Cooling
System
Clean Radiator Screen &
Fins
Engine Manual
& Page 16
X**
Engine Cooling
System
Check coolant level Engine Manual
Battery
Check Electrolyte Page 24-25
XX
Charge Battery Page 24-25
X***
Testing Battery Page 25
X
Tires
Check Air Pressure Page 10
XX X
Drive Belts
Check For Wear And
Tension
Page 16
XX
Mower Blades
Check For Wear, Damage
& Replacement
Pages 15, 21-
22
X
Mower Deck
Clean Outside & Underside
of Debris Accumulation
Page 16
X
Lubrication
Points
Grease or Oil Pages 16-17
XX
Hydrostatic
Trans. Oil
Check Oil Level Page 17
XX
Hydrostatic
Trans. Filter
Replace Filter Page 17 First Change at 200 Hours.
Thereafter every 500 Hours.
*Change oil every 25 hours when operating under heavy load or high temperatures.
** Clean more often under dusty conditions or when air debris is present
*** Charge battery every one or two months as specified by engine owner’s manual.
MAINTENANCE PARTS
4.8.1. MAINTENANCE/REPLACEMENT PARTS
MAINTENANCE PARTS
Mower Blades (52” Deck) (Hi Lift) 2-9246 (3)
Mower Blades (52” Deck) (Low Lift) 7-3395 (3)
Mower Blades (61” Deck) (Standard Lift) 1-7081 (3)
Mower Blades (61” Deck) (Hi Lift) 2-9251 (3)
Mower Blades (61” Deck) (Low Lift) 7-3396 (3)
Mower Deck Belt (52” Deck) 4-2776
Mower Deck Belt (61” Deck) 3-5542
Upper Drive Shaft To Hydro Pump Belt 3-5544 (2)
Deck Drive Shaft To Electric Clutch Belt 4-1830 (2)
Battery 3-5610
