Connecting the Wireless Headset Adapter
• UpdatethermwareofyoursnomphonetoVersion6.5.5orhigher,as
earlier versions do not support the Wireless Headset Adapter.
• Separatethephonefromthepowersupply
• Place the phone and the adapter upside down on a soft cloth or mat
so that you can read the labels from the front (see diagram). Place the
adapter to the left of the phone, with the two jacks (3.5 mm stereo jack
and RJ12 6-pin plug) pointing towards the phone.
• Connectthe6-pinextensioncordtothesnomphoneEXT-jack(1a,1b).
• -GNNetcom/Jabra:ConnecttheRJ458-pincord(2a)totheGNNetcom/
JabraEXT-jack(3a).
- Plantronics: Connect the stereo jack cord (2b) to the Plantronics stereo
jack (3b).
• ConnecttheRJ114-pincordthatcamewithyourWirelessHeadsetto
thephoneaudiojackoftheheadset(4a,4b)andtheheadsetjackofthe
phone (5a,5b).
• Connectthephoneandtheheadsettothepowersupply.
• Pressthetalkbuttonontheheadsetandcheckwhethertheheadsetis
receiving the dial tone.
• Optionally the box is shipped with a Y-cable. This cable allows to connect
the expansion module and the wireless-headset-adapter simultaneously.
Please replace 1a or 1b with the Y-cable according to the labelling.
