40
Model: Snorkel SR5719
Part Number: 159-0001-000
Snorkel International, LLC
2009 Roseport Road
Elwood, KS 66024
2.17 GENERAL SAFETY WARNINGS
Do not tamper or remove the plates and safety devices installed on the machine.
Tampering with the safety devices and failure to comply with the signs relieves the manufacturer from
liability for any damage or injury that may be caused and attributes full responsibility of the person carrying
out the actions in respect of the relevant entities.
The driver cabin is approved in accordance with the ISO 3449-2005 level II and ISO 3471-2008 (ROPS and
FOPS) standards.
ROPS = roll-over protective structure
FOPS = falling-object protective structure
The limit on which the cabin structure has been tested is 12500 kg.
If the machine that is being maneuvered is about to tip over, remain inside the cabin for the best
protection.
It is important for the safety belts to always be kept fastened to avoid being thrown out of the machine or
being crushed in case of tipping over. The safety belt is adjusted correctly when it is positioned on your
pelvis without causing particular discomfort while driving. Using the safety belt increases the sense and
level of operator safety by reducing the risk of accidents.
The back window is an emergency exit in all cabin models. ONLY IF NECESSARY, simply remove the red
retention on the compass opening handle of the window by firmly grasping the ring at one end and pulling
it downward.
Once the retainer is removed, simply push the window for it to open completely.
The area under the boom may need to be accessed for maintenance purposes, in which case, make sure
the boom cannot drop from its position, not even accidentally. For this purpose, a special metal block is
supplied on each machine, which is to be placed manually on the lifting cylinder rod, secured with screws
with a hand wheel on the rear side of the machine behind the driver cabin.
Strictly comply with the instructions to position the block defined below:
o Remove the block on the rear of the driver cabin with the two specific bolts supplied with the
machine
o Lift the boom to a height where the cylinder rod is slightly longer than the locking device.
o Climb onto the central bridge of the machine while paying attention not to step on the areas
marked with the prohibitions and place the blocking device on the cylinder rod
o Insert the two screws in the two end holes and block them in place with the relevant nuts. This
prevents the blocking device from moving out of position
