89
Model: Snorkel SR5719
Part Number: 159-0001-000
Snorkel International, LLC
2009 Roseport Road
Elwood, KS 66024
Attention! When taking a load placed at a height to put it somewhere else (again at
a height), you may be tempted to move, especially in the event of a short distance,
without lowering the load and then perform the movement with the boom extended
and the load at the top.
Do not do it! Even a small movement, especially on uneven ground, performed with
or without the load placed at the top, can generate machine oscillations and cause it to overturn (even
sideways).
4.7 LIMITS OF MACHINE USE
Never lift or transport a load that exceeds the
nominal capacity of the machine or the accessory.
Before lifting the load, check its weight and its centre
of gravity. The load diagram in the cabin refers to
lifting a load with the forks, whose centre of gravity is
at distance D (shown on the diagram) with respect to
the edge of the fork.
If the load has a mobile centre of gravity, with liquids
for example, move with precaution as it is not
possible to determine a precise rule.
4.7.1 TRANSPORTING THE LOAD
• Make sure you have selected the suitable steering mode
• Fully retract the boom
• Lift the boom slightly and bring the accessory carrier back to lift the load 300 mm from the ground
• Transport the load at a walking pace
• It is forbidden to transport loads on public roads.
