87
Model: Snorkel SR5719
Part Number: 159-0001-000
Snorkel International, LLC
2009 Roseport Road
Elwood, KS 66024
• Raise the locking rod on this side of the accessory carrier and turn it until it locks.
• Insert the connection pin supplied with the accessory carrier and turn the locking bar back to
position.
• Perform this operation also on the other side of the accessory carrier.
Release the accessory by simply performing the steps described in inverse order.
If the accessory carrier has a quick release system (optional), simply control the extension of the quick
release cylinder (on the accessory carrier) through the relevant joystick control to secure the accessory to
the accessory carrier. Release the accessory by simply retracting the cylinder using the joystick control. The
cylinder is powered by connecting a power tube to the pressure outlets located at the end of the telescopic
boom. Once the accessory is attached, the power tube can be left connected to the pressure socket unless
the assembled accessory requires it.
There are “push-pull” quick couplers. Do not insert and release the outlets when the
circuit is pressurised: risk of pressurised oil leaking. Perform these operations without
actuating the joystick control. When the pressure outlets are not used, close them with
their rubber seals. Do not work with the accessory unblocked.
If the accessory carrier is of EURO type and has a quick release system (standard), simply control the
extension of the quick release cylinder (on the accessory carrier) through the relevant joystick control to
secure the accessory to the accessory carrier. Release the accessory by simply retracting the cylinder using
the joystick control. The cylinder is powered by connecting a power tube to the pressure outlets located at
the end of the telescopic boom. Once the accessory is attached, the power tube can be left connected to
the pressure socket unless the assembled accessory requires it.
There are “push-pull” quick couplers. Do not insert and release the outlets when the
circuit is pressurised: risk of pressurised oil leaking. Perform these operations without
actuating the joystick control. When the pressure outlets are not used, close them with
their rubber seals. Do not work with the accessory unblocked.
