Snorkel TB50 User Manual

Chapter 2 – Specifications
TB42/TB50 – 0075251EE 7
General Specifications – TB50
Aerial Platform
Working height 17.2 m (56′)
Maximum platform height 15.4 m (50′ 5″)
Horizontal reach 11.9 m (39′ 1″)
Main boom
Articulation -18° to +75°
Extension 4.2 m (13′ 11.5″)
Turntable rotation 360° continuous
Turning radius, inside
Two wheel drive 1.6 m (5′ 2″)
Four wheel drive 1.7 m (5′ 6″)
Wheelbase 2.4 m (8′)
Ground clearance 25 cm (10″)
Maximum wheel load 3,075 kg (6,780 lbs)
Maximum ground pressure 4.5 kg/cm² (64 psi)
Weight, EVW
Approximate 6,442 kg (14,200 lbs)
Stowed width 2.4 m (7′ 11.5″)
Stowed length 8.1 m (26′ 9″)
Stowed height 2.3 m (7′ 9″)
Platform
Dimensions
Standard aluminum 76 cm x 152 cm (30″ x 60″)
Rated work load 227 kg (500 lb)
Optional aluminum 76 cm x 234 cm (30″ x 92″)
Rated work load 227 kg (500 lb)
Rotation 75° CW to 75° CCW
Maximum number of occupants 2 people
Optional AC generator 220 VAC
Function Speed
Turntable rotation, 360 degrees 110 to 120 seconds
Main boom
Up 52 to 57 seconds
Down 52 to 57 seconds
Extend 40 to 45 seconds
Retract 25 to 30 seconds
Platform rotation, 150 degrees 16 to 20 seconds
Drive
High, booms stowed 4.8 km/h (3.0 mph)
Low, booms elevated 1.6 km/h (1.0 mph)
Drive System
Standard Four wheel drive
Optional Two wheel drive
Gradeability 25%
Tires
Street tread, foam filled 10 ply 30 cm x 42 cm (12″ x 16.5″)
Bar lug, foam filled 10 ply 30 cm x 42 cm (12″ x 16.5″)
Electrical System
Voltage 12 V DC negative chassis ground
Source Two - 12 V 600 CCA batteries
Fluid recommended distilled water
Hydraulic System
Maximum pressure 17,237 kPa (2,500 psi)
Reservoir capacity 62.4 l (16.5 US gal)
System capacity 94.6 l (25 US gal)
Maximum operating temperature 93°C (200°F)
Hydraulic fluid recommended
Above -13°C (10°F) Mobil DTE-13M
(ISO VG32)
Below -13°C (10°F) Mobil DTE-11M
(ISO VG15)
Engine
Diesel Cummins B3.3
Diesel Deutz F3L-2011F
Fuel Tank Capacity
Diesel 75.7 l (20 US gal)
Ambient Air Temperature Operating Range
Celsius -18°C to 43°C
Fahrenheit 0°F to 110°F
Maximum Wind Speed
Gust or steady 45 km/h (28 mph)
Vibration less than 2.5 m/sec
2
Sound Threshold below 97 dB(A)
