Chapter 2 – Specications
TB60 – 0083739 5
General Specications
Aerial Platform
Working height 66′ (20.1 m)
Maximum platform height 60′ (18.3 m)
Horizontal reach 50′ (15.2 m)
Main boom
Articulation -16° to +72°
Extension 0 to 27′ 4″ (0 to 8.33 m)
Turntable rotation 360° continuous
Turning radius, inside 15′ 5″ (4.7m)
Wheelbase 10′ (3 m)
Ground clearance 13″ (33 cm)
Maximum wheel load 10,600 lbs (4808 kg)
Maximum ground pressure 64 psi (442 kPa)
Weight, GVW
Approximate 20,700 lbs (9,389 kg)
Stowed width 8′ 5″ (2.5 m)
Stowed length 30′ 10″ (9.4 m)
Stowed height 8′ 9″ (2.7 m)
Platform
Dimensions
Standard steel 39″ x 96″ (99 cm x 243 cm)
Rated work load 500 lb (227 kg)
Optional aluminum 30″ x 60″ (76 cm x 152 cm)
Rated work load 600 lb (272 kg)
Optional aluminum 30″ x 96″ (76 cm x 244 cm)
Rated work load 500 lb (227 kg)
Optional steel 30″ x 96″ (76 cm x 244 cm)
Rated work load 500 lb (227 kg)
Rotation 90° CW to 80° CCW
Maximum number of occupants 2 people
Optional AC generator 125 VAC
Optional AC generator 220 VAC, 50 Hz
Function Speed
Turntable rotation, 360 degrees 85 to 95 seconds
Main boom
Up 40 to 50 seconds
Down 40 to 50 seconds
Extend 60 to 70 seconds
Retract 50 to 60 seconds
Platform rotation, 170 degrees 16 to 20 seconds
Drive
High, booms stowed 3.0 mph (4.8 km/h)
Low, booms elevated 1.0 mph (1.6 km/h)
Drive System
Standard Four-wheel drive
Gradeability 30%
Optional Two-wheel drive
Gradeability 25%
Tires
Foam Fillled
Highway tread,14 ply 15″ x 19.5″ (38 cm x 50 cm)
Bar lug, 4x4 12 ply 15″ x 19.5″ (38 cm x 50 cm)
Flotation, 4x4 40″ x 19-19.5″ (101.6 cm x 50 cm)
Air Fillled
Flotation 40″ x 19-19.5″ (101.6 cm x 50 cm)
Electrical System
Voltage 12 V DC negative chassis ground
Source 12 V 550 CCA battery
Fluid recommended distilled water
Hydraulic System
Maximum pressure 2,500 psi (17,250 kPa)
Reservoir capacity 26.1 US gal (99 l)
System capacity 35 US gal (132 l)
Maximum operating temperature 200°F (93°C)
Hydraulic uid recommended
Above 10°F (-12°C) Mobil DTE-13M (ISO VG32)
Below 10°F (-12°C) Mobil DTE-11M (ISO VG15)
Engine
Diesel Cummins B3.3
Deutz F4L-1011F
Deutz F4L-2011F
Kubota V2403-M-T
Gasoline and/or LPG Ford LRG 423
Ford LRG 425
General Motors 2.4L
Fuel Tank Capacity
Diesel or gasoline 40 US gal (151 l)
LPG 43.5 lbs (19.7 kg)
Dual fuel gasoline 20 US gal (76 l)
Ambient Air Temperature Operating Range
Fahrenheit 0°F to 110°F
Celsius -18°C to 43°C
Maximum Wind Speed
Gust or steady 28 mph (12.8 m/s)
