Chapter 2 – Specications
4 TM12 – 8210027
General Specications
Aerial Platform
Working height 18 6(5.6 m)
Maximum platform height 12 6(3.8 m)
Minimum platform height 19 (48.3 cm)
Turning radius
Inside 14.4 (36.5 cm)
Wheelbase 38.5(97.8 cm)
Ground clearance
Pothole protector raised 3 (7.6 cm)
Pothole protector lowered 0.5 (1.27 cm)
Maximum wheel load 884 lb (401 kg)
Weight, EVW
Approximate 1,710 lbs (776 kg)
Width 30 (76 cm)
Stowed length 53.5 (1.36 m)
Stowed height 64.75 (1.64 m)
Platform
Dimensions, inside 29 x 41 (73.7 cm x 1.04 m)
Toeboard height 6(15.2 cm)
Guardrail height 43 (1.1 m)
Rated work load 500 lb (227 kg)
Maximum number of occupants
Inside 2 people
Outside 1 person
Function Speed
Platform
Up, maximum 18 seconds
Down, maximum 25 seconds
Drive
High, platform lowered 2.27 mph (3.65 km/h)
Low, platform raised 0.54 mph (0.87 km/h)
Drive System
Standard Two wheel drive
Gradeability 25% (14°)
Maximum drive height 12 (3.6 m)
Parking brake 2 wheel spring applied
Tires
Non-marking, solid rubber 12 (30.5 cm) diameter
Electrical System
Voltage 24 V DC negative chassis ground
Source Four - 6 V 220 Ah batteries
Fluid recommended distilled water
Battery duty cycle 25% for 8 hours
Battery charger 25 amp, 220 VAC
Minimum battery weight 58 lb (26.3 kg)
DC electric motor 4 hp
Hydraulic System
Maximum pressure 2,400 psi (6,1547 kPa)
Reservoir capacity 1.9 US gal (7.2 l)
Maximum operating temperature 200°F (93°C)
Minimum operating temperature -20°F (-28°C)
Hydraulic fluid recommended
Above 10°F (-13°C) Mobil DTE-13M (ISO VG32)
Below 10°F (-13°C) Mobil DTE-11M (ISO VG15)
Ambient Air Temperature Operating Range
Fahrenheit 0°F to 110°F
Celsius -18°C to 43°C
Maximum Wind Speed
Gust or steady 28 mph (12.5 m/s)
Property of American Airlines
