FEATURE IDENTIFICATION
TECHNICAL SPECIFICATIONS
Clearing Width: DB7651 26 inches
Clearing Height: 21 inches
4 Forward and 2 Reverse Speeds
Engine Displacement: 208 cc, 4 stroke
A - Drive Control Handle E - Engine I - Snow/Ice Clean Out Tool
B - Speed Control Lever F - Skid Shoe J - Chute Assembly
C - Auger Control Handle G - Augers -
D - Chute Rotation Handle H - Impeller -
