5. Connect the PVC detergent tube to the detergent
connection (Fig. 6).
6. To assemble the hose holder, slide the holder into position
(Figs. 7 & 8) and secure it to the unit with two small screws
(Fig. 9).
7. Fit the spray wand into the gun and rotate it until the two
parts are completely locked (Fig. 10).
Fig. 5
Fig. 6
Detergent tank
Detergent tube
Detergent
connection
Fig. 7
Fig. 8
Fig. 9
Fig. 10
6
