Page 11
7.2 Switching on / off
The Pico can be turned on by briey pressing the power button (6) and
can be switched off by pressing and holding the power button (6) for 2
seconds. The corresponding startup and shutdown tones will be heard
(refer to point 7.5)
Alternatively, the Pico can also be switched on and off directly from the
app (if it has been enabled in the app settings). This allows you the
convenience of switching it on if you forgot to when you attached it to
the diaper, without disturbing your baby.
7.3 Pause
The Pico was designed to monitor your baby’s breathing motion, skin
temperature and body position while sleeping. However, to prevent
false alarms while your baby is not sleeping, (such as while breast
feeding, changing the baby’s diaper, tummy time, etc.), the “Pause”
function will allow you to temporarily pause monitoring for a user-
congurable (on the app) time while, for example, breast feeding or
diaper changes.
The pause function can be activated directly from the app by tapping
the pause button.
7.4 Charging
The Pico's charging cradle (12) is a unique power charger which
recharges the built-in battery by simply placing the Pico on the
charging cradle.
7.5 Indicator Lights - Startup and shutdown sequences
Startup using power button:
When the Pico is switched ON using the power button (6), the indicator
lights (1,2,3,4) will ash in a sequence from left to right, followed by a
start-up tone. Immediately after the start-up tone, the battery indicator
light (1) will ash to indicate the state of the battery when it is switch
on. The battery indication has the following meaning:
