Sodi DD2 - 9- Table of the Standard Adjustments

DD2 MANUAL
9-STANDARD ADJUSTMENTS OF THE DD2
DRY WET
STUB AXLE HEIGHT
FRONT TRACKING WIDTH
REAR TRACKING WIDTH
POSITION OF MASSES
POSITION OF EXCENTRICS
POSITION OF STEERING
TIE RODS ENDS
DOUBLE LATERAL CRADDLE /
REAR TORSION BAR
REMOVE the double lateral
craddle.
REMOVE the torsion bar.
PLACE the double lateral
craddle.
PLACE the torsion bar
horizontally.
4mm 4mm+4mm
4mm +2mm
2mm
3 rings inside
Short hub 60mm
All rings inside
Long hub 80mm
1360 to 1370mm
1400mm
2
1
FOR TYRE PRESSURES, REFER TO TABLE PAGE 2
7
A-2
OR
B
-
3
B-3
3
3
FWD
TOP
rd
Mark - Forward
BOTTOM
Mark – Inwa
Eccentrics 4°
TOP
BOTTOM
Eccentrics 1°
FWD
Mark - Backward
Mark - Forward
- 16 -
