DD2 MANUAL
10- ADJUSTMENT OF FRONT WHEELS
10.1 ADJUSTMENT OF FRONT TRACKING WIDTH
DRY TRACK
¾ On dry track, place 3 rings inside with
SHORT HUBS L60mm.
WET TRACK
¾ On wet track, place all the rings inside with
LONG HUBS L80mm.
¾ For more grip forward, add one or
two 5 mm rings on the chassis side.
Steering becomes harder.
¾ For less grip forward, add one or
two 5 mm rings outside.
Steering becomes lighter.
3x5mm
1X15m
1
X
15m
3x5mm
- 17 -
