DIODE DIAGRAMS
12 VOLTS (+) FLOWS THIS WAY
NEGATIVE (-) FLOWS THIS WAY
SWITCHING 1 NEGATIVE (-) WIRE TO 2 NEGATIVE (-) ISOLATED WIRES
NEGATIVE (-) FEED
ISOLATED NEGATIVE (-) WIRE 1
ISOLATED NEGATIVE (-) WIRE 2
SWITCHING 1 POSITIVE (-) WIRE TO 2 POSITIVE (+) ISOLATED WIRES
POSITIVE (+) FEED
ISOLATED POSITIVE (+) WIRE 1
ISOLATED POSITIVE (+) WIRE 2
