Solamiser User Manual
n) If you wish to be able to bypass Solamiser to
provide power to your emersion heater to either
boost heating or provide heat during the winter if
your gas boiler breaks down, you can fit a switch
as shown above. This is an optional extra and
could be fitted by your electrician should you feel
the need for this facility.
14
Solamiser
L
E
N
16A
MCB
H1
Booster -break
before make change
over switch
Thermostat
Immersion + E
