SolarEdge SE17K User Manual

LCD User Buttons 44
Inverter Configuration – Setup Mode 46
Configuration Menu Options 50
Status Screens - Operational Mode 57
Chapter 7: Setting Up Communication 66
Communication Options 66
Communication Connectors 69
Removing the Inverter Cover 70
Creating an Ethernet (LAN) Connection 70
Creating an RS485 Bus Connection 74
Verifying the Connection 78
Appendix A: Errors and Troubleshooting 80
Troubleshooting Communication 80
Power Optimizer Troubleshooting 82
Appendix B: Mechanical Specifications 84
Appendix C: Connecting the AC and DCStrings to the DC Safety Unit 85
Connecting the ACGrid to the Inverter 86
Connecting the Strings to the DC Safety Unit 87
Appendix D: SafeDC™ 90
Appendix E: External Fan Maintenance and Replacement 91
Fan Maintenance 91
External Fan Replacement 91
Appendix F: Replacing and Adding System Components 93
Replacing an Inverter 93
Replacing the DC Safety Unit 94
Adding, Removing, or Replacing Power Optimizers 97
Appendix G: Determining the Circuit Breaker Size 98
Revision History 98
Introduction 98
Using Transformers in Commercial Three Phase Inverter Installations 98
Determining the Size of an Inverter Circuit Breaker 100
Technical Specifications - Single Phase Inverters (Europe &APAC) 102
Technical Specifications - Three Phase Inverters (Europe &APAC) 105
Revision History 9
Three Phase System Installation Guide MAN-01-00057-4.1

SolarEdge SE17K Specifications

General

Dimensions	540 x 315 x 260 mm
Weight	37.5 kg
Cooling	Fan (user replaceable)
Operating Temperature Range	-20°C to +60°C
Protection Rating	IP65
Rated AC Power	17000 VA
Max. DC Voltage	1000 V
CEC Weighted Efficiency	97.5%
Number of MPP Trackers	2
Ingress Protection	IP65
AC Output Power	17 kW
Noise Level	<50 dBA
Maximum Efficiency	98.0%
