Appendix

X1-SMART G2

Quick-

connect

terminal

4 / 11 485A

—

5 / 12 485B

*Note: Two terminals of different types are available for meter on X1-Smart G2, and the

pins in the same box are a pair.

DTSU666-CT

DTSU666-CT can be connected to both single-phase and three-phase inverters. Therefore,

besides the above the single-phase inverters, it is also compatible with the following three-

phase inverters.

Inverter series

Terminal Type Connector type Pin No. Pin definition

• X3-HYB G4

• X3-FIT G4

• X3-IES

RJ45

4 485A

5 485B

X3-ULTRA RJ45

4 485A

5 485B

X3-MIC G2 RJ45

4 485A

5 485B
