SolaX Power TBMS-MCR0800 User Manual

12
13
3.2
Basic Features
3.2.1 Features
3.2.2 Certifications
3.3 Specifications
3.3.1 T-BAT-SYS-HV-R2.5
3. Product Introduction
3. Product Introduction
Continued on the next page
■ Performance
The T-BAT-SYS-HV is one of the most advanced energy storage systems on the
market today, using state-of-the-art technology, and having the characteristics of
high reliability and convenient control. Characteristics are shown as follows:
■ 90% DOD;
■ 95% Battery Roundtrip Efficiency;
■ Cycle Life > 6000 Cycles;
■ Secondary Protection;
■ IP20 Protection Level and Protection Class I;
■ Safety & Reliability;
■ Small Occupied Area;
■ Floor Mounting.
■ Configuration List
UN number
UN 3480
Hazardous materials classification
Class 9
UN transportation testing requirements
UN 38.3
International protection marking
IP20, Protection Class I
BAT system safety
CE, RCM, IEC 62619, IEC 62620,
IEC 62477-1, IEC 60730 Annex H,
IEC 62040, VDE-AR-E2510, IEC
60529, UN38.3
No. Module BMS Battery Module
Nominal
Energy (kWh)
Operating
Voltage (Vdc)
1 T-BAT H R5.0 TBMS-MCR0800 × 1 TP-HR25 × 2 5.12 90-116
2 T-BAT H R7.5 TBMS-MCR0800 × 1 TP-HR25 × 3 7.68 135-174
3 T-BAT H R10.0 TBMS-MCR0800 × 1 TP-HR25 × 4 10.24 180-232
4 T-BAT H R12.5 TBMS-MCR0800 × 1 TP-HR25 × 5 12.8 225-290
5 T-BAT H R15.0 TBMS-MCR0800 × 1 TP-HR25 × 6 15.36 270-349
6 T-BAT H R17.5 TBMS-MCR0800 × 1 TP-HR25 × 7 17.92 315-406
7 T-BAT H R20.0 TBMS-MCR0800 × 1 TP-HR25 × 8 20.48 360-465
8 T-BAT H R22.5 TBMS-MCR0800 × 1 TP-HR25 × 9 23.04 405-522
9 T-BAT H R25.0 TBMS-MCR0800 × 1 TP-HR25 × 10 25.6 450-580
10 T-BAT H R27.5 TBMS-MCR0800 × 1 TP-HR25 × 11 28.16 495-636
11 T-BAT H R30.0 TBMS-MCR0800 × 1 TP-HR25 × 12 30.72 540-695
12 T-BAT H R32.5 TBMS-MCR0800 × 1 TP-HR25 × 13 33.28 585-750
Module
T-BAT H R5.0 T-BAT H R7.5 T-BAT H R10.0 T-BAT H R12.5 T-BAT H R15 T-BAT H R17.5
Nominal Voltage (Vdc) 102.4 153.6 204.8 256 307.2 358.4
Operating Voltage (Vdc) 90-116 135-174 180-232 225-290 270-349 315-406
Nominal Capacity (Ah) ①
50 50 50 50 50 50
Nominal Energy (kWh) ①
5.12 7.68 10.24 12.8 15.36 17.92
Usable Energy 90% DOD (kWh)
②
4.6 6.9 9.2 11.5 13.8 16.1
Max. Charge/Discharge Current
(A) ③
45 45 45 45 45 45
Recommend Charge/Discharge
Current (A) ⑤
30 30 30 30 30 30
Standard Power (kW) 2.56 3.84 5.12 6.4 7.68 8.96
Max. Power (kW) 4.6 6.9 9.2 11.5 13.8 16.1
Short-circuit Current (A) 2500 2500 2500 2500 2500 2500
Battery Roundtrip Effciency
(0.2C, 25°C/77°F)
Expected Lifetime (25°C/77°F)
Cycle Life 90% DOD (25°C/77°
F)
Charge Temperature
Discharge Temperature
Storage Temperature
Ingress Protection
Preotection Class
I
-4°F~122°F/-20°C~50°C (3 months)
50°F~104°F/10°C~40°C (1 year)
IP20
95%
10 Years
6000 Cycles
32°F~122°F/0°C~50°C ④
-4°F~122°F/-20°C~50°C ④
