- 9 -
3*6mm² single-phase power supply cable
Depend on actual requirement
2.1.3 Installation Process
1) Installation Notice
a) Electrical device should be installed, operated, serviced, and maintained only by qualified personnel. No
responsibility is assumed by the manufacturer for any consequences arising out of the use of this device. A
qualified person is one who has skills and knowledge related to the construction, installation and operation of
electrical device and who has received safety training to recognize and avoid the hazards involved.
b) All applicable local, regional, and national regulations must be respected when installing, repairing, and
maintaining this device.
2) Installation Procedure
1. According to the cases of the attached installation board, drill 3 - Φ 6 * 35 mm holes on the wall, and insert
the expansion pipe;
2. Lock the 2-M4*32mm self-tapping screw into the expansion pipe, and reserve 5mm space;
3. Open the top cover of charger, hang it on the automatic screw, lock it into the bottom automatic screw, and
then cover the sealing cover;
4. Connect the input power cord, close the upper cover, and lock it with 2-M4*12mm screw.
