SolaX Power X1-AE-7.0 User Manual

- 11 -
3）WIFI connection
Connect the charger to the backend through the user APP. Once the charger connected with the wifi
successfully, the charger can be used for charging.
2.3 Charging Operation
2.3.1 Connect Charger to EV
Park EV near to the charger, and plug its guns into the EV. After plug-in, please check the gun is correctly and
tightly connected. With appropriate connection, the charger LED indicator will change to flashing yellow
light, which indicates that the charger is ready for charging.
2.3.2 Start Charging & Stop Charging
After the charger is connected to EV and ready for charging, scan the RFID card for once on the identification
area of front panel or use the user APP scan the barcode on the left side of the charger, then the charging starts.
When the EV is fully charged, the charging will stop.
3 Troubleshooting
3.1 Indicator State
State
Description
LED Status
In the standby
Normal
Flashing green, 1S on, 3S off
Charging status
Normal
Breathing green, 1S on, 1S off
Plugged gun state
Normal
Green light normally on
Software upgrade
Normal
Green light flash
Ground warning
Normal
Flashing yellow, 2S on, 2S off
Relay adhesion
Fault
Red light normally on
Input polarity reverse
Fault
Flashing red, 500ms on, 500ms off, 1 time, 3S off, Cycle
CP fault
Fault
Flashing red, 500ms on, 500ms off, 2 times, 3S off, Cycle
