Solax X3-10.0P-T-D User Manual

Status
Main
menu
Setting
About
Grid
Solar
Product SN
Register SN
Master
Manager
Slave
New Password
History
Energy Reset
Export Control
Load Consume
6.2 LCD Function
Menu structure
Load
Safety
Date Time
Errorlogs Reset
Start Guide
Inverter Yield
Error Logs
Meter
6.3 LCD Operation
● LCD Digital Display
The main interface is the default interface, the inverter will automatically
jump to this interface when the system started up successfully or not
operated for a period of time.
The information of the interface is as below. “Power” means the timely
output power; “Pgrid” means the power export to or import from the
grid.“Today” means the power generated within the day.“Normal”shows
the status of the inverter.
● Menu interface
The menu interface is a transfer interface for user to get into other interface
to finish the setting or getting the information.
-User can get into this interface by pressing “OK” button when LCD displays
the main interface.
-User can select interface by moving the cursor with function button，and
press “OK” to confirm.
● Status
The status function contains three aspects of the inverter, grid, solar and
load.
Press up and down to select and press “OK” to confirm the selection, press
“ESC” to return to Menu.
a) Grid
This status shows the current grid condition such as voltage, current,
output power and grid power. Pout measures the output of the inverter,
Pgrid measures power export to or import from grid. Positive value means
the power feeds into grid, negative value means the power used from the
grid.
Press up and down button to review the parameter, press “ESC” to return to
Status .
Power 0W
Pgrid 0W
Today 00.0KWh
Normal
﹦﹦ ﹦ ﹦ Menu ﹦﹦ ﹦ ﹦
Status
History
Settings
﹦﹦ ﹦ ﹦ Status ﹦ ﹦ ﹦ ﹦
Grid
Solar
Load
Password
Load Reset
Meter Reset
Note: ” ”Can be set by the end user.
Others can only be set by the technical or the installer with the installer password.
30 31
Operation MethodOperation Method
DRM Function
Warning Reset
LineImpedance
Grid Services
Machine Type
RF Control
Grid Protection
P(freq)
Soft Start
ConditionConn
Reactive Power
P(u) Function
Power Limits
Neutral Line
Warning Logs
