INSTALLATION
Secure the supplied upper hanger onto the lower hanger using the following steps:
a. Pull the cable up through the middle hole of the
upper hanger IG (Fig.6).
b. Snap the upper hanger IG onto the lower hanger
(Fig.7).
c. Loop the cable through the upper hanger hole and
under the assembly (Fig.8).
9 10
11
5. Affix the upper hanger directly on the pool edge
using hardware kit provided (Fig.9).
6. Adjust the thumb screws so that both are touching the pool wall (Fig.10, 11).
4
