SOLE F83 - Assembly Instructions; Initial Setup and Base Assembly

8
1. Remove the treadmill from the carton and position it on a smooth, level
belt until you have removed the plastic wrap and Styrofoam from beneath
the unit. Turning the unit on its side after removing the belt may cause
the unit fold up and cause serious injury!
ASSEMBLY STEP 1
1
1. Install the six Speed Nut
Clips (128) on the Frame
Base left and right side.
2. Slide the Frame Base Caps
(61 & 62) over the Upright
tubes (4 & 5). Connect the
Lower Computer Cable (49)
to the Middle Computer
Cable (50) on the right side
of the unit.
ASSEMBLY STEP 2
2
HARDWARE STEP 2
#128. Speed Nuts
Clip (6 pcs)
F80 / F83 / F85 ASSEMBLY INSTRUCTIONS
Before attaching the hardware to Step 3, make sure the cables you just connected don’t
get pinched in between the steel tubing. If they do, this may cause issues that prevent
the treadmill from operating properly.
128
128
128
128
128
128
61
62
5
49
50
4
F83 / F85 TREADMILL
