lci1.com 574 - 537- 8 9 0 0 Rev:07.19.18
Solera
®
Power Awning 18V
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001260
Introduction
The Solera
®
Power Awning with an 18V Power Pack
features an internal motor to steadily operate the awning
and a unique, rechargeable battery that ts inside the
Solera Power Awning arm. Additionally, the pitch arm
assembly allows for rain dump and adjustable pitch
features. The pitch arm assembly also provides added
stability.
Additional information about this product can be obtained
from lci1.com/support or by downloading the free myLCI
app. Replacement component parts can be ordered from
store.lci1.com/ or by using the myLCI app. The myLCI app
is available on iTunes
®
for iPhone
®
and iPad
®
and also on
Google Play
™
for Android
™
users.
iTunes
®
, iPhone
®
and iPad
®
are registered trademarks of
Apple Inc.
Google Play
™
and Android
™
are trademarks of Google Inc.
Features
• Save 1-2 hours of additional installation expense as
there is no need to wire this awning directly in to the RV’s
power supply.
• Waterproof switch offers easy, push-button operation.
• Operates 22-25 times before needing a simple plug-in
recharge.
• Faster extend and retract time.
• Includes Easy Access AC charging adapter that plugs
into any 110V outlet.
• Easy DIY installation; no internal wiring needed to the
RV’s main power source.
Parts List
PN Description—Common Qty
237315 Rivet, AL/AL, Klamp-Tite
®
(3/16” X 1.3”) 8
281079 Screw, Zn, Hex Washer SLFDR, Blk (#6-20 X 1/2”) 2
298760 Pin, 0.093” X 2-5/16” Zn Hairpin Cotter 4
347119 Pin, 1/8” X 3”; Zn, Cotter 2
384905 Screw, SST, PNH Plain PH, (#10 - 32 X 2 1/2”) 2
384906 Nut, Nylock Plain, (#10 - 32) 2
438247 Cable Tie, Standard, NYL - 30 – White 2
CCD-
000-1260
Solera Power Awning 18V Manual 1
PN Description—434729 Qty
276611
Screw, Zn, PNH SQ SLFDR, Blk HD (#8-18 X 1/2”)
6
281154
Flat Awning, Support Arm Assy – Black
1
346891
Rivet, AL/AL, Black (3/16” X .450”);
6
360575
Screw, Zn, Waxed PNH, SQ F St, Blk (#8 - 32 X 1/2”)
2
384965
Bracket, Upper Solera Power 2.500 IN-PC Blk
2
390806
Label, Solera Power – Black
2
423751
Cap, End Power Awning - PC Black
2
656484
Flat Awning, Support Arm Assy - BP - PC Black
1
672050
Drive Head Assy w/Gear Pack w/Override - Regal -
Awning Black
1
672052
Idler Head Assy w/Gear Pack w/Override - Regal -
Awning Black
1
PN Description—434730 Qty
281152
Flat Awning, Support Arm Assy - White
1
299630
Screw, Zn, Waxed PNH, SQ F ST (#8 - 32 X 1/2”)
2
346890
Rivet, AL/AL, White, (3/16” X .450”),
6
384964
Bracket, Upper Solera Power 2.500 IN-PC White
2
390805
Label, Solera, Power – White
2
423750
Cap, End Power Awning - PC White
2
656483
Flat Awning, Support Arm Assy - BP - PC White
1
672049
Drive Head Assy w/Gear Pack w/Override - Regal -
Awning White
1
672051
Idler Head Assy w/Gear Pack w/Override - Regal -
Awning White
1
675906
Screw, Zn, PNH SQ SLFDR, (#8-18 X 1/2”)
6
