(1)
Uncover the area needed for the installation of the
collectors.
Width: width of a collector group + 0,5m (left) + 0,5m
(right)
Height: 2,5m (for one-row fields)
(2)
Install a 70/70mm support bracket on every rafter.
Place this bracket below the lowest slat and screw into
the rafter with 2 Torx 4 x 80mm screws.
(3)
Place the first collector (the left one) up on the roof.
The collector must be parallel to the rafters.
* Note: in order to cut fewer tiles during the covering
Phase, it is recommended to make sure that the
distance between the collector and edge of the tiles is
