5.5.9 Parallel System
For the general version, back-up cannot
connect in parallel. For advanced applications,
please contact our after-sales depament.
Single PV string cannot connect to multiple
inveers.
LoLoadsads
BackBack-up-up
X
One meter cannot be connected to multiple
inveers. Dierent CTs cannot connect to the
same line cable.
One batte bank cannot be connected to
multiple inveers.
The on-grid and back-up side cannot be
connected to and generator directly.
For advanced applications, please contact our
after-sales depament.
The back-up side cannot be connected on-
grid side or grid.
Grid
Back-up
On-grid
X
X
Meter
X
Generator
Back-up
On-grid
Figure 5-27


.
NOTE
