PC-Board Components / Komponenten für die Steuerung MASTER TOP
Part. No. Position on Board Part Type
3629.01 T3/T4/T5 N-CH Mosfet BUK 9535
3629.03 T8 Thyristor BT 151-500R
3629.04 D1 SI-Diode 1 N4007
3629.05 D2 Rectifier KBU8G
3629.06 IC6 U-controll T7805CT
3629.07 C1 Capacitor 4700uF/40V
3629.08 C2 Capacitor 2200uF/25V
3622.04 Halbleiterrelais semiconductor relay 200-230V
3622.02 Halbleiterrelais semiconductor relay 100-120V
3629.10 RE3 relay RY531012
3629.12 T1/T2 P-CH MOSFET 2SJ172
Not available T6/T7 T6 / T7 Transistor BC337
3621.97 IC1 µ Prozessor --
