TROUBLE SHOOTING, TECHNICAL DATA
ENGLISH 16
Error message
Possible cause
Solution
CN099:
Recov escape
Automatic fault rectification not
possible.
Rectify fault manually.
CN104:
Battery over heating
Battery overheating – battery
temperature above 60 °C, not
discharging possible
Emergency switch-off by monitoring
electronic control unit. Do not place
automatic lawnmower on base station.
Switch off automatic lawnmower and let
battery cool down.
CN110:
Blade motor over
heating
Overheated mowing motor,
temperature > 80 °C
Switch off automatic lawnmower and let
it cool down. If this reoccurs, have
automatic lawnmower checked by a
SOLO service partner.
CN119:
R-Bumper deflected
CN120:
L-Bumper deflected
Automatic lawnmower has
encountered an obstacle and
cannot move clear for safety
reasons, e.g. collisions close to
base station.
Remove obstacle and acknowledge fault
message.
CN128:
Recov Im- possible
Obstacle encountered or outside
loop -> reversing not possible,
automatic lawnmower cannot free
itself.
Remove obstacle, check cover deflection.
CN129:
Blocked WL
Left wheel motor blocked. Remove blockage.
CN130:
Blocked WR
Right wheel motor blocked. Remove blockage.
19. TECHNICAL DATA
Data evoCUT 4.0
Length / width / height in mm
600 / 490 / 245
Weight in kg
approx. 11.5
Mowing system
Electric with 2 cutting blades
Cutting blade motor rpm
3400
Cutting heights in mm
30 - 60
Cutting height adjustment 7-stage
5 mm Per stage
Cutting width in mm
320
Max. lawn to be mown in m
2
approx. 2.000
Max. slope of the lawn in %
35
Distance from boundary cable to boundary line (wall/hedge) in cm
approx. 15
Base station/transformer data
Base station connection voltage
230 V 16 A 50 HZ
Secondary voltage/current/power
27 V AC / 2,2 A / 60 VA
Noise emissions
Volume measured in dB(A) / volume guaranteed in dB(A)
63 / 65
Battery
Voltage V
25,2
Capacity Ah
4,3
Energy Wh
106 - 109
