Meaning of different parameters
Code Description Values (bold = default)
Setting
compl.
P01 Complete cycle operating
mode
0: sequential
1: sequential + timed close
2: semiautomatic
3: automatic
4: automatic + cell blocking
5: deadman's control (wire)
P02 Complete operating mode
automatic timed closing
0 to 30 ( time delay value = value x 10 s)
2: 20 s
P03 Pedestrian cycle operating
mode
0: ident. to complete cycle operating mode
1: without automatic closing
2: with automatic closing
P04 Short automatic closing
time delay in pedestrian
cycle
0 to 30 ( time delay value = value x 10 s)
2: 20 s
P05 Long automatic closing
time delay in pedestrian
cycle
0 to 99 ( time delay value = value x 5 min)
0: 0 s
P07 Cell safety input 0: inactive
1: active
2: active with autotest via test output
3: active with autotest via power supply switching
4: bus cells
P09 Programmable safety input 0: inactive
1: active
2: active with autotest via test output
3: active with autotest via power supply switching
P10 Programmable safety input
- function
0: active closing
1: active opening
2: active closing + ADMAP
3: all movement disabled
P11 Programmable safety input
- action
0: stop
1: stop + partial reversal
2: stop + complete reversal
P12 Orange warning light 0: no warning
1: with 2 s warning prior to movement
P13 Area lighting output 0: inactive
1: controlled operation
2: automatic + controlled operation
P14 Area lighting time delay 0 to 60 (time delay value = value x 10 s) - 6: 60 s
Code Description Values (bold = default)
Setting
compl.
P15 Auxiliary output 0: inactive
1: automatic: gate open indicator light
2: automatic: timed bistable
3: automatic: one-touch
4: controlled: bistable (ON-OFF)
5: controlled: one-touch
6: controlled: timed bistable
P16 Auxiliary output time delay 0 to 60 (time delay value = value x 10 s)
6: 60 s
P17 Lock output 0: active 24V one-touch
1: active 12V one-touch
P18 Lock release 0: inactive - 1: active (Control Box 3S Axovia only)
P19 Closing speed 1: slowest speed at
10: fastest speed
Default value: - Control Box 3s Axovia io: 5
- Control Box 3s Ixengo io: 6
P20 Opening speed
P21 Closing slowdown zone
0: shortest slowdown zone at
5: longest slowdown zone - Default value: 1
P22 Opening slowdown zone
P23 M1/M2 shift when closing 1: minimum shift at
10: maximum shift
Adjusted when auto-programming complete
P24 M1/M2 shift when opening
P25 M1 closing torque
limitation
1: minimum torque at
10 (Axovia) or 20 (Ixengo): maximum torque
Adjusted when auto-programming complete
P26 M1 opening torque
limitation
P27 M1 slowdown torque
limitation when closing
P28 M1 slowdown torque
limitation when opening
P29 M2 closing torque
limitation
P30 M2 opening torque
limitation
P31 M2 slowdown torque
limitation when closing
P32 M2 slowdown torque
limitation when opening
P37 Wired control inputs 0: complete cycle mode - pedestrian cycle
1: opening mode - closing
P39 Limit position maintaining
time delay
0: without time delay - 1: with time delay
(Control Box 3S Ixengo only)
P40 Coupling speed when
closing
1: slowest speed at
4: fastest speed
Default value: 2
P41 Coupling speed when
opening
Operating code display
Code Description
C1 Awaiting command
C2 Gate opening
C3 Awaiting gate closure
C4 Gate closing
C6
Detection in progress for cell safety
C8
Detection in progress for programmable safety
C9
Detection in progress for emergency stop safety
C12 Current reinjection in progress (Control Box 3S Axovia only)
C13 Safety device autotest in progress
C14 Permanent complete opening wire control input
C15 Permanent pedestrian opening wire control input
C16 BUS cell programming refused
Cc1 9.6 V power supply
Cu1 24 V power supply
Fault and breakdown code display
Code Description Comments Solution?
E1 Cell safety autotest fault The cell autotest is not satisfactory. Check that "P07" is correctly congured. Check the wiring of the cells.
E2 Programmable safety autotest fault The programmable safety input autotest is not
satisfactory.
Check that "P09" is correctly congured. Check the programm. safety input wiring.
E4 Obstacle detection when opening
E5 Obstacle detection when closing
E6 Cell safety fault Detection in progress on safety input for longer than
3 minutes.
Check that no obstacles are causing the cells or safety edge to detect.
Check that "P2" is correctly congured in relation to the device connected to the safety input.
Check the safety device wiring.
Check that the photoelectric cells are correctly aligned.
E8 Programmable safety fault
E9 Thermal protection Thermal protection is correct
E10 Motor short circuit protection Check the motor wiring.
E11 24V power supply short protection Short circuit protection for input/outputs: product and
additional devices connected to terminals 21 to 26
(orange light, photoelectric cells (except BUS), code
keypad) not operating
Check the wiring, then disconnect the power supply for 10 seconds.
N.B.: maximum accessories consumption = 1.2 A
E12 Hardware fault The hardware auto tests are not satisfactory Repeat an order. If the fault persists, contact Somfy.
E13 Accessories power supply fault The accessories power supply cuts out following an
overload (excessive consumption)
N.B.: maximum accessories consumption = 1.2 A
Check the consumption of the connected accessories.
E14 Intrusion detection Current reinjection function Normal operation (attempted intrusion, current reinjection activated, etc.)
E15 Fault when the control box supplied by the
backup battery is rst switched on
Disconnect the backup battery and connect the control box to the mains to switch it on for
the rst time.
Access to memorised data - To access memorised data, select parameter "Ud" and press "OK".
Data Description
U0 to U1 Complete opening cycle counter global [Hundred thousands - ten thousands - thousands] [hundreds - tens - units]
U2 to U3 since last auto-programming [Hundred thousands - ten thousands - thousands] [hundreds - tens - units]
U6 to U7 Cycle counter with obstacle detection global [Hundred thousands - ten thousands - thousands] [hundreds - tens - units]
U8 to U9 since last auto-programming [Hundred thousands - ten thousands - thousands] [hundreds - tens - units]
U12 to U13 Partial opening cycle counter
U14 to U15 Reset movement counter
U20 Number of monodirectional remote controls memorised for complete opening control
U21 Number of monodirectional remote controls memorised for pedestrian opening control
U22 Number of monodirectional remote controls memorised for remote lighting control
U23 Number of monodirectional remote controls memorised for auxiliary output control
U24 0 = no system key present, 1 = system key present
d0 to d9 Log of the last 10 faults (d0 most recent - d9 oldest)
dd To clear the fault log: press and hold "OK" for 7 s.
Programming code display
Code Description
H0 Awaiting setting
Hc1 Awaiting setting + 9.6 V power supply
Hu1 Awaiting setting + 24 V power supply
H1 Awaiting start of auto-programming
H2 Auto-programming mode - opening
H4 Auto-programming mode - closing
F0 Awaiting remote control memorisation for operation in complete opening mode
F1 Awaiting remote control memorisation for operation in pedestrian opening mode
F2 Awaiting remote control memorisation for remote lighting control
F3 Awaiting remote control memorisation for auxiliary output control
