Control Box 3S io
7 Copyright © 2011 Somfy SAS. All rights reserved
Checks
Safety devices (cells, safety edge)
Check correct operation every 6 months.
Backup battery
For optimum battery life, it is recommended that the main power supply be switched off and the motor operated using the battery for several cycles, three
times a year. Contact a qualied person (installer) to have the backup battery replaced.
Replacing the battery in a Keygo io remote control (Fig. 17)
MAINTENANCE
TECHNICAL DATA
Power supply 230 V - 50 Hz
Max. power consumption 800 W (with 500 W remote lighting)
Climatic operating conditions - 20°C/+ 60°C - IP 44
Somfy radio frequency io 868 - 870 MHz
Number of memorisable channels 1 W controls
(Keygo io, Situo io, etc.)
Complete/pedestrian opening control: 30
Lighting control: 4
Auxiliary output control: 4
2 W controls
(Keytis io, Telis io, Composio io, etc.)
Unlimited
Remote lighting output 230 V - 500 W
17
C
R
2
4
3
0
C
R
2
4
3
0
1
2
