Sonance SONAMP DSP 2-150 - Front Panel;Rear Panel

4
SONAMP DSP 2-150 MULTI-CHANNEL POWER AMPLIFIER INSTRUCTION MANUAL
FIGURE 3: SONAMP DSP 2-150 MULTI-CHANNEL POWER AMPLIFIER BACK PANEL
FIGURE 2: SONAMP DSP 2-150 MULTI-CHANNEL POWER AMPLIFIER FRONT PANEL
DSP 2-150 Front Panel
1. Illuminated Power Button
2. Power, Active & Protection Indicator LED
3. Recessed Volume Level Control
DSP 2-150 Rear Panel
4. L/R Line In/Loop Outputs
5. Speaker Block Connector
6. Trigger Input/Output Connector
7. IR Control In/Out
8. IR Status Light
9. RJ-45 Input
10. AC Fuse Holder
11. Power Cord Connection

   

1 2 3
5 9
11
6 7
8 104
