OPERATING MANUAL PAT-1, PAT-2, PAT-2E, PAT-10 version 1.02
32
Press MANUAL button to go to touch
leakage current measurement – icon
will be displayed.
The tester is in touch
leakage current
measurement mode.
Press SET/SEL button to set the
measurement parameters.
Use and
to set the upper limit of
leakage current.
Use and to go to the test time dura-
tion settings.
Use and
to set the test time
duration value
.
or
Press
ENTER
to confirm settings or
press ESC to exit without saving
the changes.
Connect test leads according to the drawing.
