Measurement of PRCD parameters
PRCD tripping time measurement for sine t
A
differential current
Measurement range in acc. with IEC 61557: 0ms ... up to the upper limit of displayed value
RCD type
Differential
current of
the PRCD
Rated Cur-
rent
Multiplication
Factor
Measurement
range
Resolution
Basic uncerta-
inty
General
10mA
1 I
n
0 ms..300 ms
1 ms
± 2% m. v. ±2
digits
1)
5 I
n
0 ms..100 ms
30mA
1 I
n
0 ms..300 ms
5 I
n
0 ms..40 ms
 test current flow time ............................... max. 300 ms
 AC current RCD type testing
 start of the measurement from the positive or negative half sine period of the test current
Other technical specification
a) type of insulation ...................................................... double, EN 61010-1 and IEC 61557 compliant
NOTE!
During the measurement of IΔ, IT PE of the power supply socket is
connected to PE of the test socket.
b) measurement category ....................................................................... II 300V acc. to EN 61010-1
c) protection class of enclosure acc. to EN 60529 ....................................................................... IP40
d) power supply of the tester ................................................................. 195 V…265 V, 50 Hz or 60Hz
e) load current ........................................................................................... max 16 A (230 V), max 15s
f) dimensions .......................................................................................... 200 mm x 150 mm x 74 mm
g) weight ..................................................................................................... approx. 1,40 kg (PAT-1/2)
h) storage temperature................................................................................................ –20 C...+70 C
i) operating temperature ................................................................................................. 0 C...+50 C
j) humidity ....................................................................................................................... 20 %…80 %
k) nominal temperature ............................................................................................... +20 C...+25 C
l) reference humidity ....................................................................................................... 40 %…60 %
m) altitude. ............................................................................................................................. < 2000 m
n) display ............................................................................................................................... segment
o) memory .............................................................................. 10 banks, 99 cells each (N/A to PAT-1)
p) data transfer ....................................................................................................................... USB 2.0
q) quality standards .... development, design and manufacturing are ISO 9001, ISO 14001, compliant
the product meets the EMC requirements acc. to ......... EN 61326-1:2013 and EN 61326-2-2:2013
r) This product meets the EMC (Emissions for Industrial Environment) requirements acc. to .............
........................................................................................... EN 61326-1:2013 i EN 61326-2-2:2013
