Sonos ARC User Manual

SONOS USER GUIDE
Wall mounting information
Specifications
Wall Material Pre Drill Use Wall Anchors Use Screws
Wood Stud 1/8" / 3 mm bit
No 2
Drywall (no stud) 5/16" / 8 mm bit Yes 6
Plaster 5/16" / 8 mm bit
No, requires toggle bolt
(not included)
2-6
Concrete or Brick 5/16" / 8 mm bit Yes 2-6
Feature Description
Audio
Amplifier Eleven Class-D digital amplifiers.
Elliptical Woofer Eight full-range woofers ensure you’ll hear the faithful playback of mid-range
vocal frequencies plus deep, rich bass.
Tw e e ter Three silk dome tweeters create a crisp and clear high-frequency response.
Microphones • Four microphone array.
• LED hard-wired to voice microphones for privacy control so you know
when the microphone is active.
Voice Control Integrated voice control.
System Requirements TV with HDMI ARC or optical digital audio output, broadband internet, and
the Sonos S2 app.
Networking*
Wireless Connectivity Connects to WiFi network with any 802.11 b/g/n, 2.4 GHz broadcast-
capable router.
Ethernet Port One 10/100 Mbps Ethernet port. You can wire directly to your router if your
WiFi is unstable.
General
Power Supply Auto-switching 100-240 V, 50-60 Hz 3.5 A AC universal input.
Dimensions (H x W x D) 3.4 x 45 x 4.5 in. (87 x 1141.7 x 115.7 mm)
Weight 13.78 lb (6.25 kg)
Operating Temperature 32° F to 104° F (0° C to 40° C)

Sonos ARC Specifications

General

RMS rated power	- W
Audio output channels	- channels
Audio Return Channel (ARC)	Yes
Bluetooth	-
Connectivity technology	Wired & Wireless
Number of woofer drivers	8
Number of tweeter drivers	3
Subwoofer included	No
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Certification	CE
Product color	White
Virtual assistant	Amazon Alexa & Google Assistant
Number of products included	1 pc(s)

Weight and Dimensions

Depth	115.7 mm
Width	1141.7 mm
Height	87 mm
Soundbar weight	6250 g
