SONOS USER GUIDE
Digital audio out
If your TV doesn’t have an HDMI ARC or eARC port, you’ll use the optical audio adapter (included) to connect
to your TV’s digital audio out port.
1. Remove the protective cap from the adapter.
2. Attach the optical adapter to the HDMI cable.
3. Connect the optical adapter to the TV’s optical digital OUT port.
Note: The optical adapter’s port is “D-shaped”—make sure the connector aligns correctly into the port.
Inserting the adapter incorrectly may damage the cable.
If you don’t have the free Sonos app, download it from the app store. You’ll need it to set up and control your
Sonos system. See Getting started
.
Microphone on/off
Touc h o n y ou r So no s Arc to tu r n th e mi crop ho ne on an d off. (If you don’t have a voice service installed, the
microphone is inactive.)
When the microphone light is on, voice control is on and your voice assistant is ready to respond. When the
microphone light is off, voice control is off.
Note: If you’ve installed a voice service and the microphone is off, you can still use voice commands. Just
press and hold
—no need to start with a wake word. When you release the microphone button,
voice control turns off again.
Optical adapter
HDMI cable
Remove the
protective cap

Sonos ARC Specifications

General

RMS rated power	- W
Audio output channels	- channels
Audio Return Channel (ARC)	Yes
Bluetooth	-
Connectivity technology	Wired & Wireless
Number of woofer drivers	8
Number of tweeter drivers	3
Subwoofer included	No
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Certification	CE
Product color	White
Virtual assistant	Amazon Alexa & Google Assistant
Number of products included	1 pc(s)

Weight and Dimensions

Depth	115.7 mm
Width	1141.7 mm
Height	87 mm
Soundbar weight	6250 g
