Sonos SUB User Manual

SONOS USER GUIDE
Line-in
Connect an external source like a phono preamp (your turntable may have a built-in phone preamp), or other
audio device. Learn more.
Specifications
Feature Description
Audio
Amplifier Six Class-D digital amplifiers perfectly tuned to match the six dedicated
speaker drivers and the acoustic architecture.
Tweete r Three tweeters create the crispest and clearest high-frequency response.
Mid-Woofer Three mid-woofers ensure you’ll hear the faithful playback of mid-range
vocal frequencies plus deep, rich bass—without distortion, even at high
volumes.
Phased Speaker Array (three
drivers on top and three on the
bottom)
Creates a wide stereo soundstage that directs the sound left, right, and
center.
Stereo Pair Turn two speakers into separate left and right channel speakers to create
wider, deeper sound.
Home Theater Add two speakers as surrounds for a true surround sound experience.
Networking*
Wireless Connectivity Connects to your home WiFi network with any 802.11b/g router.
You can either change the router settings to 802.11b/g or connect a Sonos
product to your router.
Bluetooth Low Energy (BLE) Temporarily connects to your mobile device for first-time set up.
Ethernet Port One 10/100Mbps Ethernet port. You can plug a Sonos product directly into
your router if your WiFi is unstable.
General
Power Supply Auto-switching 100 - 240 V ~ 50-60 Hz 2.3 A AC universal input.
Audio Line-In Auto-detecting 3.5 mm audio line-in connection.
Dimensions (W x H x D) 14.33 x 8.03 x 6.06 in. (364 x 203 x 154 mm)
Weight 14 lb / 6.36 kg
Threaded Mount None
Operating Temperature 32º to 104º F (0º to 40º C)

Sonos SUB Specifications

General

Subwoofer type	Active subwoofer
Wireless subwoofer	Yes
Subwoofer frequency range	- Hz
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Product color	Black
Wireless standard	802.11b/g

Weight and Dimensions

Subwoofer depth	158 mm
Subwoofer width	402 mm
Subwoofer height	380 mm
Subwoofer weight	16000 g
