Sonoscape S2 Operation Manual

5. How to change the image orientation?
LT/RT: In all image modes (real-time or frozen), use key to change the image left/right
orientation.
Up/Down: Press key to alternate the image orientation between up and down.
6. How to get the 2B and 4B mode?
2B: In the B mode, press button to enter into 2B mode, and use key to switch the
active image.
4B: In the B mode, press number on the PC keyboard to enter into 4B mode, and still
use key to switch the active image.
7. How to make panoramic imaging?
Press “K” key on PC keyboard, then start moving the probe to get a panoramic image and then
press “freeze”.
8. How to make the basic measurement in 2D mode?
Measurements can be done not only after freezing but also under real-time.
- Distance:
a. Press button next to trackball
b. Press button to enter into the Calculation List, choose DISTANCE under BASIC
MEASUREMENT
- Area:
a. Press button next to trackball.
b. Press button, choose AREA under BASIC MEASUREMENT
- Ellipse:
a. Press button next to trackball.
b. Press button, choose ELLISPE under BASIC MEASUREMENT
