0449P300 Installation Superstatic 449 DE EN 19-01-2012 11 Sontex SA, 2605 Sonceboz, Schweiz, Switzerland
Technische Daten Durchflusssensor Superstatic 449 Technical Data Flow Sensor Superstatic 449
qp
Gewinde-
Anschluss
Ein-
bau-
Länge
Mat. PN
Maximal
Durchfluss
qs
Minimal
Durchfluss
qi
Ansprec-
Grenze
(50°C)
Fühler-
Einbau-
Platz
Gew.
Druck-
abfall
bei qp
qp Threaded connection Length
Mat. PN
Maximal
Durchfluss
qs
Minimal
Durchfluss
qi
Low flow
threshold
value
(50°C)
Threaded
hole for
sensor
wt.
Pressure
loss at
qp
m
3
/h
G" DN mm
PN m
3
/h l/h l/h
kg bar
(EN ISO
228-1)
*0.6
3/4" (15) 110 Brass 16 1,2 6 - Yes - -
1.5 3/4"
(15)
110 Brass 16 3 15 10 Yes 1.3 0.2
1.5 1"
(20)
130 Brass 16 3 15 10 Yes 1.4 0.2
*1.5
1" (20) 190 Brass 16 3 15 10 Yes - -
*2.5
1" (20) 130 Brass 16 5 25 - Yes - -
*2.5
1" (20) 190 Brass 16 5 25 - Yes - -
* In Vorbereitung / under way Messing : Brass
Der Superstatic 449 kann ab 0.8 bar Rohrdruck eingesetzt werden. The flow sensor Superstatic 449 can be operated from 0.8 bar pipe pressure.
