Component Replacement (elect)
1246-2438 Rev 1
Sony Ericsson Mobile Communications AB – Company Internal
10(17)
Repair Actions: Additional Repair Info
5
N4401, N4402
Protect the On/Off key connector, the LED and the BtB
connector with capton tape!
6
N4802, N5500
Protect the ZIF connector with capton tape!
7
V4400
Protect the Coax connector with capton tape!
8
V4802
Protect the On/Off key connector with capton tape!
