Sony Ericsson Z1 - Additional Repair Info

Component Replacement (elect)
1246-2438 Rev 1
 Sony Ericsson Mobile Communications AB – Company Internal
8(17)
Repair Actions
3.2 Additional Repair Info
1
B5000
Protect the white LED, the BtB connector and the SIM
connector with capton tape!
2
B5500
Protect the white LED, the switch connector and the
Coax connector with capton tape!
3
L5503, L5504, L5505
Protect the Microphone, the switch connector and the
Coax connector with capton tape!
