Component Replacement (elect)
1246-2438 Rev 1
Sony Ericsson Mobile Communications AB – Company Internal
Repair Actions: Additional Repair Info
9
V5000
Protect the Vibrator, the BtB connector, the switch
connector, the white LED and the switch connector with
capton tape!
10
X1900
Protect the connector with capton tape!!
11
X1901
Protect the switch connector with capton tape!
12
X2500
Protect the Microphone, the switch connector and the
white LED with capton tape!
