1/3-inch Sony CCD Video Camera 700TV Lines, User Manual 2012-07-14
OSD Connector
6 = GND
5 = Menu Down
4 = Menu Up
3 = Select
2 = Cycle +
1 = Cycle -
Short pin to GND to activate. Pin 6 is at top when PCB is seen from behind. Turnigy OSD cable
(Product ID: 324000008) does NOT work.
Unknown Connector
1 = ???
2 = ???
3 = ???
4 = ???
OSD Setup Menu
Lens [*Manual, Auto/]
Shutter/AGC [*Auto/, Manual/]
White Bal [*ATW/, Push, User1/, User2/, Manual/, Push Lock]
Backlight [*OFF, HLC, BLC]
Pict Adjust [/]
ATR (Adaptive Tone Reproduction) [*OFF, ON/]
Motion Det [*OFF, ON/]
Privacy [*OFF, ON/]
Day/Night [*Auto/, Color, B/W/, EXT1, EXT2]
NR (Noise Reduction) [/]
Camera ID [*OFF, ON/]
Sync [*INT]
Language [*Chinese, English, ...]
Camera Reset
Exit [Save All]
* = Default
/ = Submenu by Select
