Sony Anycast station AWS-G500 User Manual

10
Specifications
* For details of RGB OUT settings, refer to “Setting the RGB Output
Signal Format” in the AWS-G500E Operating Instructions.
** For details of PGM OUT settings, refer to “Selecting the Video
Output Signal Format” in the AWS-G500E Operating Instructions.
REF OUT BNC Type × 2
Sync: 0.286 Vp-p, 75 Ω , (NTSC)
Sync: 0.3 Vp-p, 75 Ω, (PAL)
C: 0.286 Vp-p at burst, 75 Ω,
(NTSC)
C: 0.3 Vp-p at burst, 75 Ω , (PAL)
Recorder Port
HDD (in exfactory configuration)
i.LINK: IEEE1394 6-pin
Type
× 2
HDD IF: SBP2
Audio Signals
AUDIO INPUTS
Analog Inputs 1-2
XLR/TRS Combo Type
× 2
Ref. Level:
+4 dBu, −20 dBu, −44 dBu
Mic. Power:
+48 V
Analog Inputs 3-6
TRS Type
× 4 / Ref. Level:
+4 dBu, −20 dBu, −44 dBu
Analog Inputs 7-8
Pin
× 2 / Ref. Level: −10 dBu
DV IN* i.LINK: IEEE1394 (6 pins) × 4
IEC 61883−2 compliant
Audio standard level: −20 dBFS
Sampling rate:
12 bit 32 kHz 4ch (uses only
ch 1 and 2)
16 bit 48 kHz 2ch
* DV IN/OUT connectors
AUDIO OUTPUTS
PGM OUT TRS Type
× 2 / Ref.: +4 dBu /
Impedance: 150 Ω
MIX OUT Pin Type
× 2 / Ref.: −10 dBu /
Impedance: 470 Ω
AUX OUT TRS Type
× 2 / Ref.: +4 dBu /
Impedance: 150 Ω
MONITOR OUT
TRS Type
× 2 / Ref.: +4 dBu /
Impedance: 150 Ω
DV OUT* i.LINK: IEEE1394 (6 pins) × 4
IEC 61883−2 compliant
Audio standard level: −20 dBFS
Sampling rate: 12 bit 32 kHz
4ch, 16 bit 48 kHz 2ch
* DV IN/OUT connectors
HEADPHONES
1/4” Stereo Phone Jack Type × 1
70 mW × 2 / Impedance: 47 Ω
INTERCOM
D-Sub 9-pin Type (Female) /
Original Parallel I/O
Other Interfaces
NETWORK RJ-45 Type × 1, 10 Base-T/
100 Base-TX
USB USB A Type
× 2, USB equiv.
RGB (GUI) D-Sub Shrink 15-pin
× 1
(Female),
WXGA 1,280
× 800 60 Hz
REMOTE
(Provided for future functional expansion.)
D-Sub 9-pin (Male)
× 1,
RS-232C
FACTORY USE
D-Sub 15-pin
× 1 (Male),
Original Parallel I/O
MEMORY STICK
“Memory Stick” Slot
VISCA DIN 8-pin Type
× 1, RS-232C
Sony VISCA camera
commands are supported.
LCD 15.4”
WXGA (1,440
× 900* 60 Hz)
Speaker Built-In Speaker
× 2,
Size: 20
× 40 mm
Menu setting
Signal
format
FH (kHz) FV (Hz) Sync
RGB
OUT
*
PGM
OUT
**
XGA
60 Hz
-
XGA VESA
(DMT) 60 Hz
48.363 60.004
H-negative
V-negative
XGA
75 Hz
-
XGA VESA
(DMT) 75 Hz
60.023 75.029
H-positive
V-positive
SXGA
60 Hz
-
SXGA VESA
(DMT) 60 Hz
67.500 60.020
H-positive
V-positive
Video
RGB
NTSC
15k RGB
60 Hz
15.734 59.940
Composite
sync
PAL
15k RGB
50 Hz
15.625 50.000
Composite
sync
RGB
OUT
-
WXGA 60 Hz 47.693 59.992
H-negative
V-positive
WXGA 75 Hz 60.091 74.926
H-negative
V-positive
