11
Specifications
* This specification is for LCD panels on Anycast Station
units with serial numbers 15001 or later. The specification
for LCD panels on units with serial numbers earlier than
15001 is WXGA 1,280 × 800 60 Hz. The specification for
RGB (GUI) under “Other Interfaces” is WXGA 1,280 ×
800 60 Hz, regardless of serial number.
Supplied Accessories
CD-ROM (Manual) (× 1)
CD-ROM (Tutorial) (
× 1)
Notes on using the CD-ROM (
× 1)
Pin to BNC connector (
× 4)
Operating instructions (
× 2) (AWS-G500E,
AWS-G500)
Keyboard (
× 1) 85 keys + Pointer /
Infrared communication
Powered from
AWS-G500: +5 V
Battery operation: CR2032 or
CR2032H
× 2
Optional Accessories
BKAW-550 PC Video Interface Module
(mounted in slot 3 of this unit)
RGB D-Sub Shrink 15-pin Type
× 2
(Female)
XGA (1,024
× 768, 60 Hz
70 Hz 75 Hz)
SXGA (1,280
× 1,024, 75 Hz
60 Hz)
VESA (DMT) compliant
WXGA (1,280
× 768, 60 Hz)
* Input from Macintosh computers is not supported.
BKAW-560 HD Video Interface Module
YP
BPR IN D-Sub Shrink 15-pin Type × 2
(Female)
720/59.94p, 720/50p,
1080/59.94i, 1080/50i
Y: 1.0 Vp-p, 75 Ω, with Sync
P
B: 0.7 Vp-p (75 Ω)
P
R: 0.7 Vp-p (75 Ω)
YP
BPR OUT D-Sub Shrink 15-pin Type × 1
(Female)
720/59.94p, 720/50p,
1080/59.94i, 1080/50i
Y: 1.0 Vp-p, 75 Ω, with Sync
P
B: 0.7 Vp-p (75 Ω)
P
R: 0.7 Vp-p (75 Ω)
BKAW-570 SD Video Interface Module
(mounted in slots 1 and 2 of this unit)
Composite BNC Type
× 2
Video: 1.0 Vp-p, 75 Ω,
Sync negative
S-video DIN Type
× 2
Y: 1.0 Vp-p, 75 Ω,
Sync negative
C: 0.286 Vp-p at burst, 75 Ω,
(NTSC)
C: 0.3 Vp-p at burst, 75 Ω,
(PAL)
DV IN/OUT i.LINK: IEEE1394 6-pin Type
× 2
IEC 61883-2 equiv.
AUDIO INPUTS:
Ref. Level: −20 dBFS
Sampling rate: 12 bit 32 kHz
4 ch (uses only ch 1 and 2)
16 bit 48 kHz 2 ch
AUDIO OUTPUTS:
Ref. Level: −20 dBFS
Sampling rate: 12 bit 32 kHz
4 ch
16 bit 48 kHz 2 ch
HDD i.LINK: IEEE1394 6-pin Type
× 1
HDD IF: SBP2
BKAW-580/BKAW-581
*1
Serial Digital
Interface Module
SDI IN BNC × 2
VIDEO: 800 mVp-p (75 Ω)
SMPTE259M-C ITU-R656
compliant
Table of PC RGB input
Format
fH fV
Dot
clock
Sync
polarity
(kHz) (Hz) (MHz)
Hori-
zontal
Ve r ti -
cal
1,024×768
XGA VESA 60 Hz 48.363 60.004 65
Nega-
tive
Nega-
tive
XGA VESA 70 Hz 56.476 70.069 75
Nega-
tive
Nega-
tive
XGA VESA 75 Hz 60.023 75.029 78.75
Posi-
tive
Posi-
tive
1,280×1,024
SXGA VESA 60 Hz 63.981 60.02 108
Posi-
tive
Posi-
tive
SXGA VESA 75 Hz 79.976 75.025 135
Posi-
tive
Posi-
tive
1,280×768 WXGA* 60 Hz 47.693 59.992 80.125
Nega-
tive
Posi-
tive
