12
Specifications
AUDIO:
Audio sampling rate:
20 bit 48 kHz 2 channels
(channels 1 and 2 or 3 and 4)
SMPTE272M-A compliant
SDI OUT BNC × 1
VIDEO: 800 mVp-p (75 Ω)
SMPTE259M-C ITU-R656
compliant
AUDIO:
Audio sampling rate:
20 bit 48 kHz 2 channels
(channels 1 and 2)
SMPTE272M-A compliant
HDD
*2
HDD i.LINK: IEEE1394 S400
(6 pins) × 1
HDD IF: SBP2
*1 This interface module will be supported in software
version 2.30 and later.
*2 BKAW-580 only.
BKAW-590 HD Serial Digital Interface Module
HD SDI IN BNC × 2
720/59.94p, 720/50p,
1080/59.94i, 1080/50i
VIDEO: 800 mVp-p (75 Ω)
SMPTE292M compliant
AUDIO:
Audio sampling rate:
20 bit 48 kHz 2 channels
(channels 1 and 2 or 3 and 4)
SMPTE299M compliant
HD SDI OUT BNC
× 1
720/59.94p, 720/50p,
1080/59.94i, 1080/50i
VIDEO: 800 mVp-p (75 Ω)
SMPTE292M compliant
AUDIO:
Audio sampling rate:
20 bit 48 kHz 2 channels
(channels 1 and 2)
SMPTE299M compliant
Due to the internal video processing of
AWS-G500 series, the output SDI signal is not
guaranteed to be identical to the input SDI signal.
Recommended power cord
For USA and CANADA only
Part No. 1-551-812-11
For Europe only
Part No. 1-782-929-22
Design and specifications are subject to change
without notice.
Caution
Notes
• Always make a test recording, and verify that it
was recorded successfully.
SONY WILL NOT BE LIABLE FOR
DAMAGES OF ANY KIND INCLUDING,
BUT NOT LIMITED TO, COMPENSATION
OR REIMBURSEMENT ON ACCOUNT OF
FAILURE OF THIS UNIT OR ITS
RECORDING MEDIA, EXTERNAL
STORAGE SYSTEMS OR ANY OTHER
MEDIA OR STORAGE SYSTEMS TO
RECORD CONTENT OF ANY TYPE.
• Always verify that the unit is operating properly
before use. SONY WILL NOT BE LIABLE FOR
DAMAGES OF ANY KIND INCLUDING,
BUT NOT LIMITED TO, COMPENSATION
OR REIMBURSEMENT ON ACCOUNT OF
THE LOSS OF PRESENT OR PROSPECTIVE
PROFITS DUE TO FAILURE OF THIS UNIT,
EITHER DURING THE WARRANTY PERIOD
OR AFTER EXPIRATION OF THE
WARRANTY, OR FOR ANY OTHER
REASON WHATSOEVER.
