Specifications
Specifications
General
Power Requirements
AC 100 V to 240 V, 50/60 Hz
Power Consumption
1.6 A-0.8 A
Operating Temperature
5ºC to 40ºC (41ºF to 104ºF)
Dimensions (w × h × d)
424 × 114 × 339 mm
(16
3
/
4
× 4
1
/
2
× 13
3
/
8
inches)
Mass Approximately 8.0 kg
(17 lb 10 oz)
Video Signals
VIDEO INPUTS (standard configuration)
Composite BNC Type
× 4
Video: 1.0 Vp-p, 75 Ω,
Sync negative
S-video DIN Type
× 4
Y: 1.0 Vp-p, 75 Ω,
Sync negative
C: 0.286 Vp-p at burst, 75 Ω,
(NTSC)
C: 0.3 Vp-p at burst, 75
Ω
, (PAL)
DV IN* i.LINK IEEE1394 6-pin Type ×
4
IEC 61883-2 equiv.
* DV IN/OUT connectors
RGB D-Sub Shrink 15-pin
Type
× 2 (Female)
XGA (1,024
× 768, 60 Hz
70 Hz 75 Hz)
SXGA (1,280
× 1,024, 75 Hz
60 Hz)
VESA (DMT) compliant
WXGA (1,280
× 768, 60 Hz)
* Input from Macintosh computers is not supported.
VIDEO OUTPUTS
Composite BNC Type
× 1
Video: 1.0 Vp-p, 75 Ω,
Sync negative
S-video DIN Type
× 1
Y: 1.0 Vp-p, 75 Ω,
Sync negative
C: 0.286 Vp-p at burst, 75 Ω,
(NTSC)
C: 0.3 Vp-p at burst, 75 Ω,
(PAL)
DV OUT*
i.LINK IEEE1394 6-pin Type
×
4
IEC 61883-2 equiv.
* DV IN/OUT connectors
RGB (VIDEO OUT)
15k RGB (50 Hz/59.94 Hz)
R: 0.7 Vp-p (75 Ω)
G: 0.7 Vp-p (75 Ω)
B: 0.7 Vp-p (75 Ω)
SYNC: Composite sync TTL
output - audio output
RGB D-Sub Shrink 15-pin Type
× 2
(Female)
XGA (1,024
×
768 60 Hz, 75 Hz)
SXGA (1,280 × 1,024 60 Hz)
WXGA (1,280
× 768 60 Hz,
75 Hz)
Table of PC RGB input
Format
fH fV
Dot
clock
Sync
polarity
(kHz) (Hz) (MHz)
Hori-
zontal
Ve r ti -
cal
1,024 × 768
XGA VESA 60 Hz 48.363 60.004 65
Nega-
tive
Nega-
tive
XGA VESA 70 Hz 56.476 70.069 75
Nega-
tive
Nega-
tive
XGA VESA 75 Hz 60.023 75.029 78.75
Posi-
tive
Posi-
tive
1,280 × 1,024
SXGA VESA 60 Hz 63.981 60.02 108
Posi-
tive
Posi-
tive
SXGA VESA 75 Hz 79.976 75.025 135
Posi-
tive
Posi-
tive
1,280 × 768 WXGA* 60 Hz 47.693 59.992 80.125
Nega-
tive
Posi-
tive
To Next Page
