A
B13 DGND12_K Ground Digital ground
C18 DGND12_K Ground Digital ground
F21 DVCC33_IO Power 3.3V Digital IO power
G20 DVCC33_IO Power 3.3V Digital IO power
J9 DVCC33_IO Power 3.3V Digital IO power
J11 DVCC33_IO Power 3.3V Digital IO power
K8 DVCC33_IO Power 3.3V Digital IO power
L8 DVCC33_IO Power 3.3V Digital IO power
A
B4 DVCC33_IO Power 3.3V Digital IO power
A
C5 DVCC33_IO Power 3.3V Digital IO power
D21 DVCC33_IO_S TB Power 3.3V Digital IO power for Stand-By Module
E22 DVCC33_IO_S TB Power 3.3V Digital IO power for Stand-By Module
J20 DDRVCCIO Power 1.5V Digital IO power
K19 DDRVCCIO Power 1.5V Digital IO power
L19 DDRVCCIO Power 1.5V Digital IO power
L20 DDRVCCIO Power 1.5V Digital IO power
N19 DDRVCCIO Power 1.5V Digital IO power
N20 DDRVCCIO Power 1.5V Digital IO power
P19 DDRVCCIO Power 1.5V Digital IO power
R20 DDRVCCIO Power 1.5V Digital IO power
T18 DDRVCCIO Power 1.5V Digital IO power
V14 DDRVCCIO Power 1.5V Digital IO power
V16 DDRVCCIO Power 1.5V Digital IO power
V17 DDRVCCIO Power 1.5V Digital IO power
V18 DDRVCCIO Power 1.5V Digital IO power
W15 DDRVCCIO Power 1.5V Digital IO power
W16 DDRVCCIO Power 1.5V Digital IO power
W18 DDRVCCIO Power 1.5V Digital IO power
Y14 DDRVCCIO Power 1.5V Digital IO power
XTAL/PLL
A
A21
A
VDD33_MEM PLL Power 3.3V Analog Power for MEMPLL
A
B19
A
VSS33_MEM PLL Ground
A
nalog Ground for MEMPLL
A
A22 TN_MEMPLL
A
nalog Test Pin
A
B23 TP_MEMPLL
A
nalog Test Pin
H16
A
VDD12_LDO Power 1.2V standby power
F17
A
VDD33_LDO Power 3.3V power for standby
G16
A
VSS33_LDO Ground
A
nalog ground for standby
C12
A
VDD33_PLLG P Power 3.3V Analog Power for PLL Group
C13
A
VSS33_PLLG P Power
A
nalog ground for PLL Group
A
11 NS_XTALI I 27MHz Crystal In
B11 NS_XTALO O 27MHz Crystal Ou
t
A
UDIO PWM DAC interface
D12
A
VDD33_DAC Power 3.3V Analog Power
E11
A
VSS33_DAC Ground
A
nalog Ground
Multiple function:
(1) Audio output bit clock
(2) Audio PWM output
(3) GPIO
Multiple function:
(1) Audio output master clock
(2) Audio PWM output
(3) GPIO
A
udio Interface
Multiple function:
(1) 1st Audio DAC mute
(2) GPIO
Multiple function:
(1) Audio output left-right clock
(2) 2nd Audio DAC mute
(3) Video out DE signal
(4) 2nd RS232 TX
(5) External Interrupt 4
(6) Slave I2C clock
(7) PWM control signal output
(8) Ethernet Activity LED
(9) GPIO
Multiple function:
(1) Audio output serial data 0
(2) 2nd Audio DAC mute
(3) Video out DE signal
(4) 2nd RS232 RX
(5) External Interrupt 2
(6) Slave I2C clock
(7) PWM control signal output
(8) Ethernet Duplex LED
(9) GPIO
I/OAL0A10
B10
C10 AOLRCK I/O
AR0 I/O
U5 AMUTE I/O
D10 AOSDATA0 I/O
BDP-BX18/S285/S286
6-2
