Sony BDP-S186 - Page 60

(1) Audio output serial data 1
(2) Audio output master clock
(3) Microphone input master clock
(4) Video out DE signal
(5) External Interrupt 1
(6) 3th RS232 TX
(7) Slave I2C clock
(8) PWM control signal output
(9) Ethernet Activity LED
(10) GPIO
Multiple function:
(1) Audio output serial data 2
(2) Audio output bit clock
(3) Microphone input bit clock
(4) Video out DE signal
(5) External Interrupt 4
(6) 3th RS232 RX
(7) Slave I2C clock
(8) PWM control signal output
(9) External Duplex LED
(10) 1st Audio DAC mute
(11) GPIO
Multiple function:
(1) Audio output serial data 3
(2) Audio output left-right clock
(3) Microphone input left-right clock
(4) Video out DE signal
(5) External Interrupt 2
(6) 2nd RS232 TX
(7) Slave I2C clock
(8) PWM control signal output
(9) External Speed LED
(10) GPIO
Multiple function:
(1) Audio output serial data 4
(3) Microphone input data
(4) Video out DE signal
(5) External Interrupt 1
(6) 2nd RS232 RX
(7) Slave I2C clock
(8) PWM control signal output
(9) Ethernet Link LED
(10) GPIO
Multiple function:
(1) SPDIF digital audio output
(2) GPIO
Analog Video Out Interface
E16
A
VDD33
_
VDA C Power
3.3 V Analog Power
D16
A
VDD33
_
VDA C
_
R Power
3.3 V Analog Power
G14
A
VSS33
_
VDAC Ground
A
nalog Ground
F14
A
VSS33
_
VDAC
_
R Ground
A
nalog Ground
A
18 VDACB
_
OUT
A
nalo
g
DAC output
C18 VDACG
_
OUT
A
nalo
g
DAC output
C17 VDACR
_
OUT
A
nalo
g
DAC output
B18 VDACX_OUT Analog
DAC output
Digital Video Output Interface
Multiple function:
(1) Video o
u
t mode
:
CLOCK
(2) 2nd RS232 TX
(3) Slave I2C clock
(4) PWM control signal output
(5) Ethernet Activity LED
(6) NAND Flash Data input/output bit 5
(7) Secure Disk interface clock
(8) GPIO
Multiple function:
(1) Video out mode: HSYNC
(2) 2nd RS232 RX
(3) Slave I2C data
(4) External Interrupt 1
(5) Ethernet Duplex LED
(6) NAND Flash Data input/output bit 7
(7) Secure Disk interface command
(8) GPIO
VOUTCLKF22
I/OVOUTHSYNCH22
I/OAOSDATA2C8
I/OSPDIFA7
AOSDATA3D7
I/O, 5VAOSDATA4
C9 AOSDATA1 I/O
C7
I/O, 5V
I/O, 5V
Multiple function:
Multiple function:
6-3
BDP-BX18/S285/S286
