Multiple function:
(1) Video out mode: VSYNC
(2) 3th RS232 TX
(3) External interrupt 2
(4) Ethernet Speed LED
(5) NAND Flash Data input/output bit 6
(6) Secure Disk interface data bit 0
(7) GPIO
Multiple function:
(1) Video out 16-bit 422 mode:C0
(2) External Interrupt 4
(3) 3th RS232 RX
(4) Ethernet Link LED
(5) NAND Flash Data input/output bit 4
(6) Secure Disk interface data bit 1
(7) GPIO
Multiple function:
(1) Video out 16-bit 422 mode:C1
(2) Slave I2C clock
(3) NAND Flash Data input/output bit 3
(4) Secure Disk interface data bit 2
(5) GPIO
Multiple function:
(1) Video out 16-bit 422 mode:C2
(2) Slave I2C clock
(3) NAND Flash Data input/output bit 2
(4) Secure Disk interface data bit 3
(5) GPIO
Multiple function:
(1) Video out 16-bit 422 mode:C3
(2) JTAG ICE data out
(3) GPIO
Multiple function:
(1) Video out 16-bit 422 mode:C4
(2) JTAG ICE clock
(3) GPIO
Multiple function:
(1) Video out 16-bit 422 mode:C5
(2) JTAG ICE data in
(3) GPIO
Multiple function:
(1) Video out 16-bit 422 mode:C6
(2) JTAG ICE data in
(3) GPIO
Multiple function:
(1) Video out 16-bit 422 mode:C7
(2) Audio line input data
(3) GPIO
Multiple function:
(1) Video out 16-bit 422 mode: Y0
(2) Microphone input master clock
(3) 2nd RS232 TX
(4) Slave I2C clock
(5) PWM control signal output
(6) Ethernet Activity LED
(7) NAND Flash Data input/output bit 1
(8) GPIO
Multiple function:
(1) Video out 16-bit 422 mode: Y1
(2) Microphone input bit clock
(3) 2nd RS232 RX
(4) Slave I2C clock
(5) External Interrupt 1
(6) Ethernet Duplex LED
(7) NAND Flash Data input/output bit 0
(8) GPIO
Multiple function:
(1) Video out 16-bit 422 mode: Y2
(2) Microphone input left-right clock
(3) 3th RS232 TX
(4) Slave I2C clock
(5) External Interrupt 2
(6) Ethernet Speed LED
(7) NAND Flash ready/busy
B25
I/OVOUTD5F24
I/OVOUTD7E24
I/OVOUTD8C25
I/OVOUTD9D24
I/O, 5VVOUTD10
I/OVOUTD6D25
I/OVOUTD3G23
I/OVOUTD4E25
I/OVOUTD1G24
I/OVOUTD2F25
I/OVOUTVSYNCG21
I/OVOUTDOG25
6-4
BDP-BX18/S285/S286
(8) GPIO
